Dado Set
| TEETH | ||
|---|---|---|
 |  |  |
| Left Blade | Chippers | Right Blade |
| CUTS | ||||
|---|---|---|---|---|
 |  |  | ||
| Chipboard | Softwoods | Hardwoods | ||
Adjustable Stacked Dado Blade Set
Flat-Bottom Precision Grooving
The Stacked Dado Blade Set is engineered for precise dado, rabbet, and groove cutting in professional woodworking applications. Built with two outer blades featuring a 4+1 tooth configuration (four beveled teeth plus one flat tooth) and flat-tooth chippers, the set produces true flat-bottom cuts without ridges—ensuring high-quality results for joinery, cabinetry, shelving, and furniture construction.
Constructed with CERATIZIT-grade carbide tips and a German-quality alloy steel plate, this dado set delivers excellent durability, cutting stability, and smooth performance across solid wood, MDF, laminate, and plywood. With 20+ adjustable cutting widths ranging from 1/4" to 29/32", it provides exceptional flexibility for both precision grooving and high-efficiency production environments.
Key Features
- Corner Relief
Compensates for cutting tool wear, preventing uneven cutting from affecting bottom seating. - Adjustable Widths
Over 20 groove sizes (1/4" to 29/32") can be achieved using included chippers and spacers. - Superior Cutting in Dense Panels
Clean, accurate grooves even in MDF, plywood, and laminate materials. - Durable Construction
CERATIZIT-grade carbide tips and German steel body extend blade life and cutting stability. - Multiple shims
Precisely adjust cutting width by inserting thin shims between blades and chippers to achieve exact dado groove dimensions. - OEM / ODM Support
Full customization and private-label manufacturing available.
Applications
- Furniture Manufacturing
Cabinet doors, drawer bottoms, and shelving joints. - Custom Woodworking
Tailored joinery for high-end carpentry projects. - Panel Processing
Consistent grooves in MDF, plywood, and laminate. - Joinery & Dado Cutting
Professional-grade performance for precision wood joints.
Looking for a precision dado set?
Contact GOLDEN EAGLE today to configure your custom set or request OEM/ODM solutions.
| Diameter | Teeth | Bore | Hook | Item ID | Specification |
|---|---|---|---|---|---|
| 6" | 20T/4T Chipper* | 5/8" | -5 | DA620 | 6"×24T-5/8" |
| 8'' | 24T/4T Chipper* | 5/8" | -5 | DA824 | 6"×24T-1" |
| 8" | 24T/4T Chipper* | 1" | -5 | DA824N10 | 8"×24T-5/8" |
| 8" | 40T/8T Chipper* | 5/8" | 20 | DA840 | 8"×24T-1" |
| 8" | 40T/8T Chipper* | 5/8" | -2 | DA840N | 8"×40T-5/8" |
| 8" | 40T/8T Chipper* | 1" | -2 | DA840N10 | 8"×40T-1" |
| 10" | 40T/8T Chipper* | 5/8" | 20 | DA1040 | 10"×40T-5/8" |
| 10" | 40T/8T Chipper* | 1" | 20 | DA104010 | 10"×40T-1" |
